Frequency Response

50 Hz – 25 kHz

Nominal Impedance

6 ohms

Sensitivity (1W@1M)

90 dB

Maximum SPL

111.6 dBA

Power Handling (RMS)

120 W

Recommended Amplifier Requirements

30 – 120 W

Drive Unit Complement

8"  cone bass driver
1"

Adjustment Controls

HF Level Switch ( 3 dB / 0 dB / -3 dB)

Overall Diameter (Including Grille)

441 x 288 mm (17^3/8 x 11^5/16")

Overall Depth (Including Grille)

104 mm (4^1/8")

Mounting Depth

100 mm (3^15/16")

Cut-Out Hole Diameter

387 x 234 mm (15^1/4" x 9^3/16")

Fixing Type

6 position  dog fixings

Construction Material

Mineral filled ABS, RoHS compliant

Weight

3.08 kg (6 lb 12 oz)

Pre-Construction Bracket

Back Box

Sold As

Single Unit
