Detect, monitor, and report critical flow zone data and total system flows with this robust and simple-to-install flow sensor. Add wireless flow-monitoring capabilities to Hydrawise® Systems with a simple and affordable communication kit.

• Type Wired or Wireless
• Versatile: Wireless communication kit for use with any HC Flow Meter and Hydrawise-enabled HC, HPC, Pro-HC, or HCC controller
• Convenient: Sends station-level flow rates and totals wirelessly from the sensor to the controller, without the need to run wire or dig trenches
• Effective: Provides 152 m line-of-sight communication from transmitter to receiver.

Operating Specifications

• Scaled pulse output is precalibrated from the factory based on the size of the meter
• When wired directly to the controller, the meter must be installed with shielded, minimum 18 AWG wire, up to 1,000' from the controller
• Accuracy: ± 2% of reading at recommended flow

Wireless Operating Specifications

• 500' range (line of sight) from transmitter to receiver
• Communication frequency: 900 MHz for use in North America
• Transmitter power supply: 3 AA batteries
• Receiver power supply: 24 VAC from host controller
